MOBILE WIND MACHINE MK1
Technical specifications
Mobile wind Machine > MODEL MK1
| Engine | Petrol - HONDA 23 CV (2 V-engine cylinders «Industrial Type») |
| Tank | 60 litres |
| Consumption | 5 litres / hour |
| Dimensions (Open) | Maximum height : 8 metres Wind machne diameter : 2 metres |
| Dimensions (Closed) | Length : 585 cm Width : 232cm Height: 285cm |
| Transport | Tractor or SUV |
| Setup | 180° / 360° |
| Stability | 4 telescopic legs |
| Tower operation | Hydraulic |
| Propeller material | Cast aluminium |
| Proppelled air speed | 20 m/s (protected area - up to 3,5 Ha) |
| Sound level | 45 dB / 300 m |
| Controller | Standard |
| Operation | Automatic start via temperature probes in the upper and in the lower part |
| Security | Anemometer |
| Maintenance | Lubrication and refueling can be done in lowered position |
This mobile wind machine can be placed on flat lands, in valleys or mountains.
Thanks to the modifiable angle of the fan, the anti-frost tower allows optimal protection.
MK1 does not require support base or building permits, it is incredibly quiet and has low energy consumption.
PROTECTION Wind Machine FOR CROPS, SETUP ON LEGS THE MOST EFFICIENT ON THE MARKET…
Flexibility, antifreeze protection, ventilation, cooling system
In order to benefit from thermal inversion, the tower must be put into operation when the temperature is still positive between +0,5° and +1,5° (wet temperature).
The use of heater when the temperature reaches the critical point, allows an increase to +2°C of the temperature of the protected area.
With black frost, without thermal inversion, the use of the tower with an external heat source is essential.
* Theoretical layout under the influence of air mass, with positive thermal inversion, air humidity of 75%, non-dry soils, without winds, with sufficient heating, within the limit of a white frost of -2.5°C. This document has only an indicative and non-contractual informative value, not engaging the responsibility of RN7AS, nor the results obtained.
